Coated with heat-resisting polymer film & features heating Precise technology & cutting-edge carbon fiber surface heater.
CARBON FIBER & CNT synthetic process applied
conductive fiber designs & electrode placement process applied
P/U series of thin layer insulating material laminating process applied
POLY-SEMI CONDUCTOR manufacturing technology
Power-saving, over-hating resistant PTC active element adopted / applied
Heating treatment for CARBON FIBER conductive function technology
Through spinning/weaving technology, conductive fiber design & electrode placement process applied
Consumers’ needs are considered in designs of finished product MAT
Power-saving type, Over-heating resistant PTC active element adopted/applied. Product manufacturing with over-heating resistant & energy saving type technology conversion Prototype made
| Specification | 1000 mm in width, 3 METER in length, Heater thickness within 3mm |
|---|---|
| Performance | Heating temperature 35 degree or over, temperature deviation within ±5℃,Power consumption within 150W/M2within - Purpose: Saving type fiber carbonized heater for heating |
| Feature | Ultra-slim fiber heater without electromagnetic interchanging |
Conductive type carbonized heating resistance material manufacturing - Power-saving effect enhanced through structured designs (Power-saving type150W/m2 , thermal conversion efficiency 90 %) - Manufactured fiber heater with heating resistance materials with flexibility & durability
DC 24v/12v power without electromagnetic interchanging Insulation coating material P/U laminating process technology
Conductive power like metal power or thin layer type claddings are used electrode, for mechanical fastening on the bonding sections with conductive fiber and to have arc created & carbon resistant
| Chinese Patented | NO.201010193737.1 KP1807 Application date 2010.08.10 |
|---|---|
| U.S.A. Patented | US12/872.874 Application date; Aug. 30 2010 U.S.A. international Patented Registration date;2013.11.02 |
| KoreanPatented | 10-1129251 Registration date 2012.01.31 |
PTC(Positive Temperature Coefficient ) Temperature self-induction type active element -Not ceramic, but polymer type semi-conductor element Module manufacturing process - Electrode connector are continuous multi-process to ensure the automated 15 processes and high productivity implementations Features -Automatic conversion in phase at over constant temperature (Curie temperature) Competitiveness -Uniqueness in element manufacturing technology development & affordable production cost
Insert heating units [single or dual] in waist back.
Insert DC plug in In/Out port of the battery.
Press On/Off button[
] of the battery and set a Number[1,2,3,4,5] for the temperature as you want.
Note : “5” is the highest, but “4” is enough in normal conditions.
* A Number indicating remained capacity will automatically be shown 3 seconds later after setting the temperature choice.
As you touch one-time, the temperature step is changed. If you press one more time after the “5”, Off is followed.
☞OFF-1-2-3-4-5-OFF
When the battery is not connected with the heating units, “E” mark will be shown in 30 seconds,
then a Number indicating remained capacity appears.
Thanks for your purchasing REDZEN. REDZEN is passed strict testing.
Warranty period[non-sequential damages]is one year without payment.[But 6 months for the battery!]
After the warranty period, payment is needed for repairs.
Paid repairs
1) Damages on users carelessness.
2) Damages on fire, earthquake, flood disasters.
3) Damages in case users did not keep cautions
4) In case of missing warranty card or unknown sellers, unknown buying date.
For repairs, a warranty card is needed.
Fatal defects are found.
Received products are different from your ordered Products.
In case one week is passed after receiving products.
Damages by user’s carelessness.
Already used ones.
Missing and broken packaging & description sheets.
Mobility, flexibility, durability, safety, good fit, DC fiber heating material used is resistant to electromagnetic interference and radio environment can be used in a variety of (Thickness 0.2mm, 1 minute can be increased to 70 ℃)
